DECOR-200 CRZ Soler & Palau bathroom extract fan with timer Ø120 (ball bearings)

Connection diameter Ø120 mm
Airflow185 m³/h
Sound level45 dB(A)
Power20 W

€111.15 Incl. VAT

€91.86 excl. VAT

Soler & Palau DECOR-200 CRZ high-performance Ø120 mm axial bathroom extractor fan with adjustable timer and ball bearings, delivering 185 m³/h airflow at 45 dB(A). Provides reliable air extraction in bathrooms, WCs and shower rooms of 8–15 m², with a slimline front grille and automatic backdraft shutter.

  • Fast delivery across Europe (5-10 business days)
  • 30-day returns
  • No customs duties within the EU
  • Secure payments
Overview

Soler & Palau DECOR-200 CRZ Bathroom Extractor Fan with Timer

Combining timer-controlled extraction with a durable ball-bearing motor, this Ø120 mm axial bathroom exhaust fan delivers 185 m³/h airflow at 45 dB(A). The adjustable 1–30 minute run-on timer, set with a regulator on the circuit board (PCB) behind the front grille, extends ventilation after the switch is turned off, helping clear residual humidity, condensation, steam and unwanted odours from rooms of 8–15 m².

The integrated automatic backdraft shutter helps prevent reverse airflow and limit heat loss when the extractor is not operating. Ball bearings support reliable long-term motor operation, while the slimline white front grille provides a clean, compact appearance for residential bathroom ventilation. The fan has a neon light indicator.

DECOR-200 MODEL FEATURES

Soler And Palau DECOR-200 Series Bathroom Extractor Fan Model Features With Ball Bearings On Z Models

TECHNICAL INFORMATION

Soler And Palau DECOR-200 Bathroom Extractor Fan Technical Data Ø120 mm 185 m³/h 20 W 45 dB(A) 2500 rpm

DIMENSIONS

Soler And Palau DECOR-200 Bathroom Extractor Fan Dimensions 180 × 180 × 108 mm With 25 mm Front Grille Depth

APPLICATION

Suitable for bathrooms, WCs, shower rooms and utility rooms of 8–15 m², providing effective extraction of humidity, condensation, steam, stale air and unwanted odours. The run-on timer provides additional ventilation after use, while the ball-bearing motor supports reliable operation for regular residential bathroom ventilation. The fan is suitable for wall or ceiling mounting and operates at air temperatures from 0 to 40 °C.

Specifications
Performance
Airflow (m³/h)185
Sound level (dB(A))45
Speed (rpm)2500
Number of Speeds1 speed
Speed controlFixed speed
Motor & electrical
Power (W)20
Electrical supplySingle phase
Voltage (V)230
Frequency (Hz)50
IP ratingIPX4
Protection ClassClass II
Motor insulation classClass B
Thermal overload protectionYes
Ball BearingsYes
Pilot lightYes
FunctionsTimer
Backdraft shutterYes
Dimensions & installation
Connection diameter Ø (mm)120
Temperature range (°C)up to +40
Weight1 kg
Product codes
BrandSoler & Palau
SeriesDECOR
Product typeBathroom and WC extract fan
MaterialPlastic
ColorWhite
Country of originSpain
Manufacturer Code5210103700
BAR/EAN8413893126368
